Model NS9595-5V-60mA
Dimensions 95.0 mm * 95.0 mm * 2.0 mm
Maximum operating voltage, Vop (With 83 load) 5.0 V
Maximum operating current , Iop (With 83 load) 60.0 mA
* Open-circuit voltage, Voc 7.0 V
* Short-circuit current , Isc 95.0 mA
Test Condition AM 1.5 (100mW/cm2) and 25°C
Model NS9595-4V-75mA
Dimensions 95.0 mm * 95.0 mm * 2.0 mm
Minimum operating voltage, Vop (With 53 load) 4.0 V
Minimum operating current , Iop (With 53 load) 75.0 mA
* Open-circuit voltage, Voc 5.6 V
* Short-circuit current , Isc 105.0 mA
Test Condition AM 1.5 (100mW/cm2) and 25°C
